User Manual

Navigate UPawsion effortlessly with insights from our concise user manual.

Horizontal Feeder (Basic Version)

◎ Safety Instructions:

  1. Always supervise children when using.
  2. Not suitable for pets unable to access the food tray or with disabilities.
  3. Avoid immersing the base in water; it can damage electronic parts.
  4. Keep foreign objects out of the feeder.
  5. Refrain from using canned or wet food.
  6. Do not attempt to disassemble.
  7. Avoid modifications.
  8. If faulty or damaged, don’t self-repair; contact the seller.
  9. Unplug when not in use or cleaning.
  10. If the plug is wet, switch off the socket's power and avoid unplugging.

◎ Notice

  1. Prevent pets from chewing/swallowing accessories. For power cord safety, consider a wire conduit from a hardware store.
  2. Place the feeder in a sheltered location. Ensure temperatures are between -10°C and 40°C.
  3. Use only alkaline Size D batteries. Avoid rechargeables.
  4. Regularly check the battery. If away for extended periods, replace it beforehand.
  5. For lifting, grip the base with both hands. Keep upright and don't lift by the cover or tray.
  6. Suitable for dry food, 3-13mm in diameter. Larger pieces may jam the outlet.
  7. Thoroughly review and adhere to all provided instructions.

◎ Button Guide

  • Recording Button: Long press for 3 seconds until you hear a "Beep" to begin recording; once you've recorded for up to 10 seconds or release the button, a "Beep-Beep" sound will confirm the recording is saved. If you're unsatisfied, you can repeat the process to overwrite the previous recording.
  • Up/Reset Button: Use this to switch between numbers. Additionally, when the screen is locked, long press for 5 seconds to reset both the time and feeding settings.
  • Setting Button: Engage this to access and modify settings.
  • Unlock Key: On a locked screen, press and hold for 3 seconds to unlock, changing the icon to the unlocked state and restoring all functions.
  • Down Key: Use to toggle numbers during setting operations.
  • Feed Key: A short press serves one portion of food. If a recording exists, it will play twice simultaneously.
  • Note: The screen auto-locks after 30 seconds of inactivity.

◎ Cleaning and Maintenance

  1. For the health of your pet, ensure the feeder is cleaned regularly.
  2. If you notice accumulated dirt or loose food in the food trough, detach the food cover for cleaning.
  3. Wipe the feeder base and control panel gently using a soft, damp cloth. Avoid wetting this section.
  4. Refrain from directly rinsing with water.
  5. Never place the product in the dishwasher as it can cause irreversible damage.

◎ Specification

  • Food Tank Capacity: 5L
  • Screen: LCD display
  • Power Supply: DC 5V/1A adapter or 3 Alkaline Type-D Batteries
  • Power Adapter: AC110-240V with DC5V output
  • G.W: 1.95KG
  • Size: 28.5×17.5×30.2cm

◎ Setting Schedule Feeding

  1. Unlock Screen: Press and hold the unlock key for 3 seconds.
  2. Initiate Time Setting: Long press the setting button for 3 seconds. The time icon "0000" will flash, indicating hour setting mode.
  3. Hour Setting: Use the up/down buttons to select the desired hour.
  4. Minute Setting: Press the set button to move to minutes. Adjust minutes using the same method as for hours.
  5. Meal Quantity: After setting the current time, press the set button. The display will then flash the number of meals, which can be set between 1-4 using the up/down buttons. (e.g., A flashing "3" signifies 3 meals per day.)
  6. Meal Time Setting: Press the set button. The hour segment of the time icon will flash. Adjust using the up/down buttons. Then, press the set button again to adjust minutes, using the up/down buttons.
  7. Feeding Portion: Press the set button, and the feeding portion number will flash. Adjust the portion using the up/down buttons.
  8. Additional Meals: If setting more than one meal, press the set button and repeat steps 6 and 7 for meals 2 through 4 as required.

◎ Recording

  • To start recording, press and hold the record button for 3 seconds until you hear a "Beep" sound. Recording is limited to 10 seconds. Once you release, a "Beep-Beep" sound will confirm the save. To playback, simply press the record button.
  • To replace a recording, follow the process described above.
  • When it's feeding time, the feeder will dispense food and play the recording simultaneously.

◎ Manual Feeding

  • Once the screen is unlocked, press the feed key to dispense food one portion at a time. (This action won't impact the scheduled feeding plan.)

◎ Restore Factory Setting

  • When the screen is locked, press and hold the Up button for 5 seconds to reset all settings, including time, feeding plan, meal portions, and recordings.
Horizontal Feeder (WiFi Version)

◎ Safety Instructions:

  1. Always supervise children when using.
  2. Not suitable for pets unable to access the food tray or with disabilities.
  3. Avoid immersing the base in water; it can damage electronic parts.
  4. Keep foreign objects out of the feeder.
  5. Refrain from using canned or wet food.
  6. Do not attempt to disassemble.
  7. Avoid modifications.
  8. If faulty or damaged, don’t self-repair; contact the seller.
  9. Unplug when not in use or cleaning.
  10. If the plug is wet, switch off the socket's power and avoid unplugging.

◎ Notice

  1. Prevent pets from chewing/swallowing accessories. For power cord safety, consider a wire conduit from a hardware store.
  2. Place the feeder in a sheltered location. Ensure temperatures are between -10°C and 40°C.
  3. Use only alkaline Size D batteries. Avoid rechargeables.
  4. Regularly check the battery. If away for extended periods, replace it beforehand.
  5. For lifting, grip the base with both hands. Keep upright and don't lift by the cover or tray.
  6. Suitable for dry food, 3-13mm in diameter. Larger pieces may jam the outlet.
  7. Thoroughly review and adhere to all provided instructions.

◎ Button Guide

  • Recording Button: Press and hold for 1s until a "Beep" sound is heard to start recording. Release after a maximum of 10 seconds or when the "Beep-Beep" sound indicates the recording is saved.
  • Delete Recording: To erase a recording, press and hold for 1s until you hear "Beep". Press for another second and release when you hear "Beep-Beep". Essentially, you're overwriting the old recording with silence.
  • Factory Reset: Press and hold for 7 seconds until three beeps are heard. The red/blue indicator then remains lit for 6 seconds before switching to a slow flash.
  • FEED: A short press dispenses 1 portion of food and plays the recording once.
  • Lock/Unlock: Press and hold FEED Button for 6 seconds until the red indicator flashes twice, locking the device. To unlock, hold again for 6 seconds until the red light flashes twice.

◎ Blue Indicator Light:

  1. Fast Flashing: Blinks twice every second, indicating WiFi quick connection mode.
  2. Slow Flashing: Blinks once every 3 seconds, signaling AP hotspot network configuration mode.
  3. Steady On: Indicates successful network connection.
  4. Power On/Switch Mode: Remains lit for 6 seconds during WiFi quick connection/AP mode toggle.

◎ Red Indicator Light:

  1. Flashing: Detects an issue with the limit switch (motor doesn't rotate).
  2. Lock/Unlock: Flashes twice.
  3. Power On/Switch Mode: Remains lit for 6 seconds during WiFi quick connection/AP mode toggle.

◎ Cleaning and Maintenance

  1. For the health of your pet, ensure the feeder is cleaned regularly.
  2. If you notice accumulated dirt or loose food in the food trough, detach the food cover for cleaning.
  3. Wipe the feeder base and control panel gently using a soft, damp cloth. Avoid wetting this section.
  4. Refrain from directly rinsing with water.
  5. Never place the product in the dishwasher as it can cause irreversible damage.

◎ Specification

  • Food Tank Capacity: 5L
  • Screen: LCD display
  • Power Supply: DC 5V/1A adapter or 3 Alkaline Type-D Batteries
  • Power Adapter: AC110-240V with DC5V output
  • G.W: 1.95KG
  • Size: 28.5×17.5×30.2cm

◎ Recording

  • To start recording, press and hold the record button for 3 seconds until you hear a "Beep" sound. Recording is limited to 10 seconds. Once you release, a "Beep-Beep" sound will confirm the save. To playback, simply press the record button.
  • To replace a recording, follow the process described above.
  • When it's feeding time, the feeder will dispense food and play the recording simultaneously.

◎ Lock/Unlock

  • Press and hold Feed button for 6 seconds until the red indicator light flashes twice, locking the device. To unlock, press and hold again for 6 seconds until the red indicator flashes twice.

◎ Manual Feeding

  • Once the screen is unlocked, press the feed key to dispense food one portion at a time. (This action won't impact the scheduled feeding plan.)
Horizontal Feeder (Camera Version)

◎ Safety Instructions:

  1. Always supervise children when using.
  2. Not suitable for pets unable to access the food tray or with disabilities.
  3. Avoid immersing the base in water; it can damage electronic parts.
  4. Keep foreign objects out of the feeder.
  5. Refrain from using canned or wet food.
  6. Do not attempt to disassemble.
  7. Avoid modifications.
  8. If faulty or damaged, don’t self-repair; contact the seller.
  9. Unplug when not in use or cleaning.
  10. If the plug is wet, switch off the socket's power and avoid unplugging.

◎ Notice

  1. Prevent pets from chewing/swallowing accessories. For power cord safety, consider a wire conduit from a hardware store.
  2. Place the feeder in a sheltered location. Ensure temperatures are between -10°C and 40°C.
  3. Use only alkaline Size D batteries. Avoid rechargeables.
  4. Regularly check the battery. If away for extended periods, replace it beforehand.
  5. For lifting, grip the base with both hands. Keep upright and don't lift by the cover or tray.
  6. Suitable for dry food, 3-13mm in diameter. Larger pieces may jam the outlet.
  7. Thoroughly review and adhere to all provided instructions.

◎ Button Guide

  • Recording Button: Press and hold for 1s until a "Beep" sound is heard to start recording. Release after a maximum of 10 seconds or when the "Beep-Beep" sound indicates the recording is saved.
  • Delete Recording: To erase a recording, press and hold for 1s until you hear "Beep". Press for another second and release when you hear "Beep-Beep". Essentially, you're overwriting the old recording with silence.
  • Factory Reset: Press and hold "Play" Button for 7 seconds until three beeps are heard. The red/blue indicator then remains lit for 6 seconds before switching to a slow flash.
  • FEED: A short press dispenses 1 portion of food and plays the recording once.
  • Lock/Unlock: Press and hold FEED Button for 6 seconds until the red indicator flashes twice, locking the device. To unlock, hold again for 6 seconds until the red light flashes twice.

◎ Blue Indicator Light:

  1. Fast Flashing: Blinks twice every second, indicating WiFi quick connection mode.
  2. Slow Flashing: Blinks once every 3 seconds, signaling AP hotspot network configuration mode.
  3. Steady On: Indicates successful network connection.
  4. Power On/Switch Mode: Remains lit for 6 seconds during WiFi quick connection/AP mode toggle.

◎ Red Indicator Light:

  1. Flashing: Detects an issue with the limit switch (motor doesn't rotate).
  2. Lock/Unlock: Flashes twice.
  3. Power On/Switch Mode: Remains lit for 6 seconds during WiFi quick connection/AP mode toggle.

◎ Cleaning and Maintenance

  1. For the health of your pet, ensure the feeder is cleaned regularly.
  2. If you notice accumulated dirt or loose food in the food trough, detach the food cover for cleaning.
  3. Wipe the feeder base and control panel gently using a soft, damp cloth. Avoid wetting this section.
  4. Refrain from directly rinsing with water.
  5. Never place the product in the dishwasher as it can cause irreversible damage.

◎ Specification

  • Food Tank Capacity: 5L
  • Screen: LCD display
  • Power Supply: DC 5V/1A adapter or 3 Alkaline Type-D Batteries
  • Power Adapter: AC110-240V with DC5V output
  • G.W: 1.95KG
  • Size: 28.5×17.5×30.2cm

◎ Recording

  • To start recording, press and hold the record button for 3 seconds until you hear a "Beep" sound. Recording is limited to 10 seconds. Once you release, a "Beep-Beep" sound will confirm the save. To playback, simply press the record button.
  • To replace a recording, follow the process described above.
  • When it's feeding time, the feeder will dispense food and play the recording simultaneously.

◎ Lock/Unlock

  • Press and hold Feed button for 6 seconds until the red indicator light flashes twice, locking the device. To unlock, press and hold again for 6 seconds until the red indicator flashes twice.

◎ Manual Feeding

  • Once the screen is unlocked, press the feed key to dispense food one portion at a time. (This action won't impact the scheduled feeding plan.)
